Dense Design and Excellent Performance

Designed for demanding workloads, with I/O capabilities to maximum VMs per server and support for HPC tasks and clusters, this is an ideal option for different operations in data centers or space-constrained offices. The dense 1U server offers powerful Intel processing and configurable RAM, three PCIe gen3 expansion slots along with readily available storage space for enhanced performance.

Customize your Network Fabric

Customize network capabilities with Dell R620 10Gb NIC and increase output with powerful processing and I/O features. Network adapters and daughter cards allow network fabric configuration to suit your application demands without a need for a PCIe slot. Choose speed, adapter type and bandwidth (from 1Gb to 10Gb NICs), independent partitioning switch, and other options to customize your network fabric.

Support for a Variety of RAID Controllers

0, 1, 5, and 10 RAID configurations are supported to ensure data security and improve performance when configured with SATA HDDs or SSDs. They help replace drives through split mirrors and offer physical disk power management by managing extra or idle drives to reduce power and operations costs. Dell R620 RAID controllers include PERC S110, H310, H710, H710P, and H810.

Powerful Processing with Two Intel Xeon CPUs

The Intel C602 chipset can support one or two Intel Xeon processors, supporting 12 cores per processor and 24 for two. CPU compatibility ranges from Intel E5-2600 or E5-2600 v2 series, E5-2603, 2640, E5-2628L, etc. Dell R620 specs like 1866MT/s DDR3 RAM, up to 10TB scalable storage, GPU support, integrated RAID and management contribute to overall high server performance.

Key Features

Reliable, available and serviceable features including flexible hot-plug drives, titanium power supply, integrated iDRAC7 management and redundant hypervisor enable this server to supporta general and wide range of workloads. This Grade A quality 1U server with a high memory footprint and I/O expansion can meet the demands of virtualization, network collaborations and data centers.

Flexible Options for High-performance Storage

Dell PowerEdge R620 has large storage space and reliable hard drive compatibility that includes SAS or SATA SSDs and HDDs and can fit 10x 2.5-inch drives.

Easily Configurable DDR3 ECC Memory

It has highly configurable RAM with 24 DIMM slots, providing 1.5TB of max memory. Common Dell R620 memory configurations include 8x8GB, 8x16GB, 16x26GB, 16x32GB of DDR3 ECC registered memory.

Improved Systems and Remote Management

Integrated iDRAC7 allows simplified management and remote access to the IT network. Improved system maintenance and performance is achieved through Lifecycle Controller for updates, deployment and monitoring.

Enhanced Performance with More GPU Cards

Dell R620 GPU technology accelerates the performance of various applications and VDI. It supports a 75W graphics card from NVIDIA Quadro 2000, 600, or ATI Firepro V5800.

Server Management

Quick Delivery Around the World

Around the world, instant shipping and doorstep delivery are available. We work with only trusted shipping partners to deliver your servers safely to your address.

Round-the-clock Installation & Tech Support

We have 24×7 online client support throughout the year and we also have certified and experienced staff to provide free installation and technical support.

Assured Warranty

We offer the best three-year warranty services wherein repairs or placements of spare parts like RAM, storage drives, networking cards, fans, etc can be done for free.

Questions? We're here to help

From offering expert advice to solving complex problems, we've got you covered.

Additional information

Server Brand	DELL
Server Density	1U
Family	PowerEdge
Processor Brand	Intel
Processors	Intel Xeon processor E5-2600 and E5-2600 v2 product families
Cores	4, 6, 8, 10, 12
Maximum Cores	24
CPU Slots	2
Memory Size	768GB
Memory Type	DDR3
Memory Slots	24
PCIe Slots	3
Supported OS	Linux Server, Microsoft Windows
Hard Drive Size	10TB
Server Generation	12th
Power Supply	1100W, 750W
